Street/Strip Transmission; Max 800 HP/650 ft./lbs. Torque; For Use w/ HPM Compushift Controller;
B&M Racing’s GM 4L80E Street/Strip transmission is a complete ready to run unit (less converter) for high performance Street/Strip use for GM model years 1993 to 1996. The Street/Strip 4L80E transmission is packed with performance features such as providing firm shifts, a high energy intermediate band, new overdrive sprag assembly, new low roller assembly and all new performance friction materials. Other features include all new steel foward hub, solenoids, wiring harness, recalibrated forward pattern automatic valve body and performance pump assembly. This transmission is built to handle up to 800 HP/650 lb-ft of torque. Notes: For transplant applications, this transmission requires an electronic controller such as B&M ShiftPlus2 transmission controller #120001. Carbureted applications will require a throttle position sensor (TPS) #120002. To prevent contamination of worn parts circulating through your new B&M transmission, we strongly suggest replacing or adding a new B&M SuperCooler transmission cooler.
GTIN: 00019695001643
Automotive Item Grade: High Performance
California Proposition 65 Chemical Name 1: Lead
California Proposition 65 Chemical Name 2: Chromium (hexavalent compounds)
California Proposition 65 Chemical Name 3: Benzene
Cooler Included: No
Dipstick Included: No
Disclaimer: Transmission shipped without speedometer driven gear or housing
Drive Type: RWD
Friction Plate: New
Horsepower Rating: 800
Input Shaft Spline Quantity: 32
Intermediate and Low Roller Clutches: Included
Package Contents: Transmission
Torque Capacity: 650 ft/lbs.
Torque Converter Included: No
Trans Model: GM- 4L60E (Auto) 4 Speed
Transmission Model: 4L80E
Transmission Pan Finish: Natural
Transmission Pan Material: Steel
Transmission Pan Type: Stamped
Valve Body Configuration: Recalibrated
Valve Body Pattern: Forward
Valve Body Type: Automatic
WARNING CA Proposition 65: No
Emissions : Released
Life Cycle Status: Available To Order
Quantity of Each: 1
Package UOM: EA
